304SSC Gusset Bag Horizontal Pouch Packing Machine Premade 40mm Depth
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | Alpha Pack |
| Certification: | CE |
| Model Number: | APHPM-250G |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1unit |
|---|---|
| Price: | USD15000-20000 per unit |
| Packaging Details: | Export Wooden Case |
| Delivery Time: | 30days per month |
| Supply Ability: | 10units per month |
|
Detail Information |
|||
| Material: | #304SSC | Voltage: | 380V 3PH 50HZ Or 220V 3PH 60HZ |
|---|---|---|---|
| Automatic Grade: | Automatic Filling And Sealing | Machine Type: | Bag Packing Machine |
| Warranty: | One Year | Driving Type: | Electric |
| High Light: | 304SSC Horizontal Pouch Packing Machine,Gusset bag Horizontal Pouch Packing Machine,40mm Depth automatic bag filling and sealing machine |
||
Product Description
Automatic Horizontal Type Filling and Sealing Packing Machine (Gusset Premade bag)
Model: APHPM-250G
The bag must be gusset type punches
Technical data:
Max. speed: about 10ppm (empty run, real speed will depend on filling volume, pouch type and machine adjustment)
Bag size (length) : 150-400 mm
Gusset depth: 40-140mm
Bag size (width): 100-250 mm
Electric connection: 380V 3PH 50HZ / 220V 3-phase,60 Hz
Machine size:
Working position description and procedure:
Total 3 working position as following:
#1 Pouch magazine & pick-up the pouch
#2 Bag open and products filling (bag’s top open by hand gripper) and bottom opened by vacuum cup)
#2 Option: gas flush device (option)
#3 Sealing position (heat seal ) and feed out conveyor
Machine Equipment:
1. English touch screen display
2. Include one timing hoper for one bag width (Size to be confirmed)
3. Servo motor controlled the bag moving
4. ”Yudian” PID temperature controller 48*48
5. 304 stainless steel machine framing
6. Vacuum pump to provide vacuum for pouch pickup and opening, reliable, lower noise and less maintenance.
7. “Panasonic” PLC and “Kinco” control system to control whole machine (as standard).
