Vertical Form Fill Seal Packaging Machine

Vertical Form Fill Seal Packaging Machine

Product Details:

Place of Origin: China
Brand Name: Alpha Pack
Certification: CE
Model Number: PM-420

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: USD20000-25000
Packaging Details: standard export wooden case
Delivery Time: 50 workdays
Payment Terms: T/T L/C
Supply Ability: 20 sets per month
Get Best Price Contact Now

Detail Information

Name: Automatic Vertical FFS Machine Keyword: VFFS Machine
Speed: 35-40 Ppm Film: Laminated Film
Material: Painting Case Or 304 Stainless Steel
High Light:

220V VFFS Packing Machine


Granule VFFS Packing Machine


35ppm Form Fill Seal Packing Machine

Product Description

Automatic Vertical Form Fill Seal Packing Machine

Model:  PM-420



Model PM-420
Max measuring range 1000ml
Bag length(mm) 80-300
Bag width (mm) 80-200
Film width (mm) 180-430
Speed (bag/min) 30-40
Power supply 1ph/220V, 2.5kw





Automatic packaging of granule powder and powder in formed bag for the food, pharmaceutical, chemical industries etc.



1. The machine can automatically finish the products conveying, measuring, feeding, filling and bag forming, bag printing, bag sealing & cutting;

2. Servo motor driven, twin-belt film pulling system;

3. High sensitive sensor can trace color mark accurately;

4. PLC control system combined with touch screen, can easily set and change the packing parameters, daily production output and self-diagnostic machine error can be viewed directly from the screen;

5. PID temperature controller monitors heat sealing temperature within ±1.

6. Selected electrical and pneumatic components from reliable international manufacturer.

7. CE certificated can comply with CE standard.


Optional parts

1. Gusset forming device;

2. printer;

3. Pouch top hole pouch;

4. #340 stainless steel machine case.
