100pcs/Min PLC Horizontal Flow Wrapper , Biscuits 70mm Pack Height Food Packaging Machine
Product Details:
| Place of Origin: | China |
| Brand Name: | Alpha Pack |
| Certification: | CE |
| Model Number: | AHP-400S |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | USD 7000-10000 per set |
| Packaging Details: | standard export wooden case |
| Delivery Time: | 20 workdays |
| Payment Terms: | T/T L/C |
| Supply Ability: | 20 sets per month |
|
Detail Information |
|||
| Keywords: | Biscuits Packaging Machine | Speed: | 60-100 Ppm |
|---|---|---|---|
| High Light: | 100pcs/min Horizontal Flow Wrapper,PLC Horizontal Flow Wrapper,70mm Pack Height Food Packaging Machine |
||
Product Description
Horizontal Flow Wrapper Biscuits Foods Packaging Machine
| Model No. | AHP-400S | AHP-500-3S |
| Wrapping speed: | up to 100 pcs/min. | up to 250 pcs/min. |
| Max. Film reel width: | 400mm | 500mm |
| External film reel dia.: | 350mm | 350mm |
| Max. package height: | 70mm | 100mm |
| Max. package width: | 200mm | 200mm |
| Min. package length: | 60mm | 76mm |
| Max. package length: | 452mm | 564mm |
| Compressed air pressure: | 6bar | 6bar |
| Supply voltage : | 220-240v1ph | 380-400v3ph |
| Power consumption : | 2.5kw | 3.0kw |
| AHP-400S | AHP-500-3S | |||||||
| φ114 | φ144 | φ144 | φ174 | |||||
| 1SP | 2SP | 1SP | 2SP | 1SP | 2SP | 1SP | 2SP | |
| Max. Length (mm) | 357 | 178 | 452 | 226 | 452 | 226 | 564 | 273 |
| Min. Length (mm) | 120 | 60 | 151 | 75.3 | 151 | 75.3 | 182 | 91 |
| Max. Height (mm) | 40 | 40 | 70 | 70 | 70 | 70 | 100 | 100 |
*The Max. Measures cannot be obtained all three together
Features
- Advanced PLC control system combined with 5.7″ Colorful touch screen control panel, can easily set and change packing parameters, display production data and self-diagnostic machine error can be viewed directly from the screen.
- Servo driving system, film speed automatically synchronized with conveyor speed
- End seal jaw speed adjustable by a hand wheel when bag length change.
- All parts are built for easy maintenance and cleaning.
- Pulling wheels open by means of pneumatic switches. The sealing wheels open automatically at every machine stop.
- Safety guards as required by European law. Comply with CE standard.
- On all Machines is possible to install: Photocell for printed film, Printer for date, line shaft for automatic feeders, etc.
